The Cudy POE24-12W is a passive PoE adapter operating at 10/100M speed and providing 24V 12W power output. This model is designed to supply both data and power over a single Ethernet cable to compatible Cudy wireless devices such as the LT500 Outdoor, AP1200 Outdoor, and LT400 Outdoor. Operating with Mode B pin assignment, the adapter offers reliable connectivity up to 100 meters using Cat.5 or higher cables. Its technical strengths include surge, ESD, overvoltage, and short-circuit protection. With EMC protection compliant with IEC/EN 61000-4-2 and IEC/EN 61000-4-5 standards, it ensures stable operation even in industrial environments. It features a 100-240V AC input range for worldwide use and a three-prong plug for installations requiring grounding. The plastic casing and compact dimensions (80.1×48.9×31.9 mm) allow both desktop and wall-mount installation. This adapter is used for powering passive PoE devices such as outdoor access points or long-range wireless bridges. In home or small office networks, it eliminates the need for an extra power cable by being placed between the switch and the compatible device. It is also a practical option for users who want to add a quick and low-cost PoE solution to an existing network infrastructure. Technical Specifications: - Model: POE24-12W 1.0 - Input Port: 1x 10/100M RJ45 - Output Port: 1x 10/100M RJ45, Passive PoE - PoE Pin Assignment: Mode B - Power Input: 100-240V AC, 50/60Hz, 0.4A - Max Power Output: 12W, 24V DC, 0.5A - Transmission Distance: 100 meters (Cat.5 or higher cable) - Protection: Surge, ESD, Overvoltage, Short-Circuit - Operating Temperature: 0°C - 40°C - Dimensions: 80.1 x 48.9 x 31.9 mm - Casing Material: Plastic - Certifications: FCC, CE, CCC
