The Cudy GS1010P is a high-performance switch offering 8 Gigabit PoE+ ports and 2 Gigabit uplink ports with a total PoE budget of 120W. Supporting IEEE 802.3at/af PoE standards, it delivers up to 30W per port, providing both data and power over a single cable for devices such as IP cameras, wireless access points, and VoIP phones. Designed for 24/7 uninterrupted operation with a robust metal casing and built-in power supply. Technically, the GS1010P offers a switching capacity of 20 Gbps and a forwarding rate of 14.88 Mpps, ensuring smooth network traffic management. 9 KB jumbo frame support increases efficiency for large file transfers. The device features a DIP switch with VLAN, Default, and Extend modes for flexible configuration. When Extend mode is enabled, ports 1-8 support transmission distances up to 250 meters, while VLAN mode isolates downstream ports to enhance security. Additionally, the PoE Watchdog feature automatically reboots unresponsive PoE devices to maintain network stability. This switch is ideal for medium-sized businesses and campus environments for security camera systems, wireless network infrastructures, and digital signage solutions. Its compact metal casing with standard 1U height easily fits rack or desktop installations. The built-in power supply eliminates the need for an external adapter and provides grounding support with a three-prong plug. It can serve as a reliable PoE backbone for both office networks and outdoor camera systems. Technical Specifications: - Gigabit RJ45 PoE+ Ports: 8 (ports 1-8) - Gigabit RJ45 Uplink Ports: 2 - Total PoE Power Budget: 120W - Max PoE Power per Port: 30W - PoE Standard: IEEE 802.3at/af - Switching Capacity: 20 Gbps - Forwarding Rate: 14.88 Mpps - MAC Address Table: 2048 - Jumbo Frame Support: 9 KB - Packet Buffer: 1 Mbit - Power Input: 100-240V AC, 50/60Hz - Power Consumption (excluding PoE): 10W - Operating Temperature: 0°C ~ 40°C - Storage Temperature: -40°C ~ 70°C - Operating Humidity: 10% ~ 90% (non-condensing) - Casing Material: Metal - Dimensions: 200 x 118 x 44 mm - Weight: 663.3 g - DIP Switch Modes: VLAN, Default, Extend - Extend Mode Distance: 250 meters (ports 1-8) - PoE Management: Intelligent Power Management, PoE Watchdog - EMC Immunity: IEC/EN 61000-4-2 (ESD) Level 3, IEC/EN 61000-4-5 (Surge) Level 4 - Grounding: Three-prong plug
